13″ x 24″ Metal Lathe with Stand – Craftex CX-Series
Featuring a 13″ swing over bed, 24″ distance between centers, and a 1.5HP powerful motor, this lathe can tackle a variety of jobs. The CX709 is precision-crafted for superior accuracy, durability, and long lasting dependable service. The combination of belt & gears settings allows user to choose from speeds ranging 65 – 1650 RPM and the four-way tool post makes operation fast and efficient.
Like all CX-Series machines, this unit features powder-coated paint, sharp two-tone colours, overall heavy-duty construction, and 3 year warranty.

SPECIFICATIONS

Motor Power: 1.5 HP, 110V, 11Amp
Max. Swing over bed: 13″
Max. Length of workpiece: 24″
Max. Swing carriage: 8.5″
Bed width: 6.2″
Spindle Bore: 1.5″
Spindle Taper: MT 5#
Spindle Speeds: 12 Steps
Spindle Speeds Range: 65—1650RPM
Max. Lateral Stroke over tool post: 6.2″
Max. Longitudinal stroke of tool post: 4″
Metric Thread kinds: 17 Kinds
Metric Thread range: 0.5-4 mm
Inch Thread kinds: 24 Kinds
Inch Thread range: 8-40 TPI
Longitudinal–feed range: 0.1-1.396mm/r
Cross–feed range: 0.025-0.34mm/r
Tailstock Quill Diameter: 1.5″
Travel of Tail-stock Quill: 2.7″
Tail-stock Quill Taper: MT 3#
Net Weight: 240kg

Lathe comes with:

Steady Rest
Follow Rest
Face Plate
3 Jaw Chuck
4 Jaw Chuck
Stand
Splash Guard
